OWC Mercury Helios 3S Thunderbolt 3 PCIe Enclosure + Blackmagic DeckLink Duo 2 For Sale

OWC Mercury Helios 3S Thunderbolt 3 PCIe Enclosure + Blackmagic DeckLink Duo 2
When you click on links to various merchants on this site and make a purchase, this can result in this site earning a commission. Affiliate programs and affiliations include, but are not limited to, the eBay Partner Network.

Buy Now

OWC Mercury Helios 3S Thunderbolt 3 PCIe Enclosure + Blackmagic DeckLink Duo 2:
$549.99

OWC Mercury Helios 3S + Blackmagic DeckLink Duo 2

Turnkey 4-Channel SDI I/O Over Thunderbolt 3 | Apple Silicon Tested | Used Twice

What This Is

A complete, working solution to a specific problem: you have a Mac or PC with no PCIe slots, and you need multiple channels of professional SDI capture and playback.

The Blackmagic DeckLink Duo 2 gives you four fully independent 3G-SDI connections, each configurable as input or output in any combination. The OWC Mercury Helios 3S puts that card on the end of a single Thunderbolt cable. Plug it into a MacBook Pro, Mac mini, Mac Studio, iMac, or any Thunderbolt laptop and you have four channels of broadcast SDI.

Bought separately these two pieces run roughly $750 to $830 new. This is both, tested together and ready to go.

Verified on Apple Silicon, Current macOS, Current Firmware

This is the question everyone asks about a DeckLink in a Thunderbolt chassis, so here is the direct answer. Tested yesterday on a Mac Studio with Apple M1 Ultra running macOS Tahoe 26.5.2. The enclosure enumerated over Thunderbolt immediately, the DeckLink Duo 2 was recognized by Blackmagic Desktop Video with no troubleshooting, and the card was updated to the latest Blackmagic firmware while connected.

Blackmagic DeckLink Duo 2
  • 4 x offerirectional 12-bit SD/HD SDI, each independently configurable as input or output
  • Effectively four separate capture or playback cards in one
  • Formats up to 1080p60, plus 1080i, 1080PsF, 720p, NTSC and PAL
  • 16 channels of embedded SDI audio in and out, 48 kHz 24-bit
  • Reference input accepting black burst or tri-level sync for genlocking to studio timing
  • 10 and 12-bit processing, 4:2:2 and 4:4:4 sampling
  • Hardware real-time colorspace conversion and down, up, and cross conversion
  • SMPTE 259M, 292M, 296M, 372M and 425M compliant, with RP 188 timecode and closed caption support
  • Works with DaVinci Resolve, Premiere Pro, Final Cut Pro, Media Composer, After Effects, Nuke, OBS, vMix and more via the free Blackmagic Desktop Video drivers
OWC Mercury Helios 3S
  • Thunderbolt 3 at up to 40 Gb/s, Titan Ridge controller
  • PCIe 3.0 x4 interface in a physical x16 slot, for half-length full-height cards
  • Two Thunderbolt 3 ports, one with 85W power delivery to charge a laptop while you work, one with 15W, and daisy-chain support for up to five further Thunderbolt devices
  • Dedicated DisplayPort 1.4 output supporting up to an 8K display
  • Tool-less design with thumbscrews, so swapping to a different PCIe card later takes under a minute
  • Aluminum chassis
  • Fully compatible with Thunderbolt 4, Thunderbolt 5, and USB4 computers, as the Apple Silicon testing above confirms
Condition

Nearly perfect. Used twice.

The aluminum enclosure is clean and straight with no dents, drops, or finish damage, showing only the faintest handling marks. All five BNC connectors are clean and bright with straight center pins and undamaged threads. Thumbscrews are present and turn freely. Thunderbolt, DisplayPort, and DC connectors are clean and undamaged. Rear labeling and serial are crisp and fully legible.

The interior is clean with no dust accumulation. The card is properly seated and the cooling fan spins freely with no bearing noise. Interior photos are included in this listing so you can see exactly what you are getting.

The OWC power supply and IEC cable are in excellent condition with intact strain relief. Smoke-free, climate-controlled use.

Tested

Tested on a Mac Studio with Apple M1 Ultra running macOS Tahoe 26.5.2. The chassis enumerates over Thunderbolt, the DeckLink Duo 2 is recognized by Blackmagic Desktop Video, and the card is running the latest Blackmagic firmware. Fan and power supply operate normally.

Included
  • OWC Mercury Helios 3S enclosure, S/N 2938009741
  • Blackmagic Design DeckLink Duo 2 card, installed
  • OWC power supply, 12V 12.5A
  • IEC power cable
    Shipping and Returns

    Double boxed with the chassis immobilized and the power supply packed separately, fully insured. 30 day returns accepted.

    Message me with any questions before buying and I will answer promptly.
